EXPANDED METAL
| Pattern Number | L.W.M (mm) | S.W.M. (mm) | Strand Width (mm) | Strand Gauge (mm) | % Free Area | Approx. Kg/M2 |
| MF876 018 | 6.05 | 3.38 | 0.8 | 0.5 | 50 | 2.1 |
| MF877 018 | 10.24 | 5.84 | 0.8 | 0.5 | 75 | 1.2 |
| MF888 036 | 10.24 | 5.84 | 1.2 | 0.9 | 65 | 3.2 |
| MF889 036 | 14.27 | 5.84 | 1.2 | 0.9 | 60 | 3.2 |
| MF890 036 | 19.05 | 7.42 | 1.2 | 0.9 | 60 | 3.4 |
| MMF 020R | 5.80 | 3.50 | 0.8 | 0.6 | 44 | 2.1 |
